CMM Software and Programming
CMM Programming
Request a quotation for part program development or revision.
- ✓Work performed under ISO/IEC 17025:2017
- ✓Serving Southwest Ohio and the Ohio Valley
- ✓As-found data recorded before adjustment
- ✓Certificate states method, conditions and uncertainty
Request a quotation
Inspection Routines Built to the Print
Programs are written or revised against the customer's print and GD&T callouts, checking each feature in the order the part is actually built and measured. Datum structure, tolerance zones and feature callouts are read from the drawing before a single point is taken on the machine.
Existing routines can be updated after a model revision, a fixture change, or a software migration without rewriting the full program from scratch. Collision checks and probe access are verified on a dry run before a revised routine is handed back for production use.
Programming Scope
Work covers new program development, revision of existing routines, and software migration across common CMM platforms.
New program development
Inspection routines built from the part print and tolerance callouts.
Program revision
Existing routines updated after a design change or fixture update.
Software migration
Legacy programs converted for current metrology software versions.
Offline programming
CAD-based routines generated before the part is ever loaded on the machine.
Program Development Steps
Print review
GD&T callouts and datum structure are reviewed against the CAD model.
Routine built
The inspection sequence is written against the fixture and part orientation.
Dry run verified
The program is run and checked for collisions and probe access.
Delivered with report
The finished routine is delivered with a sample inspection report.
Why Cincinnati CMM Calibration and Repair
GD&T-based routines
Programs are built from datum structure and tolerance callouts, not just surface points.
Multiple software platforms
Programming support spans common CMM software in use across the region.
Revision without rebuild
Minor design changes are handled as targeted edits, not a full rewrite.
Coverage across Southwest Ohio and the Ohio Valley
Service area includes Cincinnati and surrounding Southwest Ohio and Ohio Valley communities. On-site availability varies by equipment type and location.
Discuss CMM Programming Requirements
Request a quotation for a new or revised inspection program.
